經典PLC主機

2025-03-11 13:32:20 43523


海為PLC 可編程控制器介紹海為PLC 在通訊方面的特點及優勢 海為HaiwellHappy - PLC編程軟件的特點

? 海為PLC產品性能規格 ? 海為PLC通訊地址代碼及安裝方式 ? 海為PLC應用指令列表

C系列經典PLC主機 ?海為C系列PLC主機使用說明

帶以太網型號		型號		產品規格				外形尺寸 WxHxD
24V DC	220V AC	24V DC	220V AC	DI	DO	通訊口	最大擴 展模塊	外形尺寸 WxHxD
C10S0R-e	C10S2R-e	C10S0R	C10S2R	6	4 繼電器	RS232 + RS485	無	93×95×82mm
C10S0T-e	C10S2T-e	C10S0T	C10S2T	6	4 晶體管NPN	RS232 + RS485	無
C10S0P-e	C10S2P-e	C10S0P	C10S2P	6	4 晶體管PNP	RS232 + RS485	無
C16S0R-e	C16S2R-e	C16S0R	C16S2R	8	8 繼電器	RS232 + RS485	無
C16S0T-e	C16S2T-e	C16S0T	C16S2T	8	8 晶體管NPN	RS232 + RS485	無
C16S0P-e	C16S2P-e	C16S0P	C16S2P	8	8 晶體管PNP	RS232 + RS485	無
C24S0R-e	C24S2R-e	C24S0R	C24S2R	16	8 繼電器	RS232 + RS485	無	131×95×82mm
C24S0T-e	C24S2T-e	C24S0T	C24S2T	16	8 晶體管NPN	RS232 + RS485	無
C24S0P-e	C24S2P-e	C24S0P	C24S2P	16	8 晶體管PNP	RS232 + RS485	無
C32S0R-e	C32S2R-e	C32S0R	C32S2R	16	16 繼電器	RS232 + RS485	無
C32S0T-e	C32S2T-e	C32S0T	C32S2T	16	16 晶體管NPN	RS232 + RS485	無
C32S0P-e	C32S2P-e	C32S0P	C32S2P	16	16 晶體管PNP	RS232 + RS485	無
C48S0R-e	C48S2R-e	C48S0R	C48S2R	28	20 繼電器	RS232 + RS485	無	177×95×82mm
C48S0T-e	C48S2T-e	C48S0T	C48S2T	28	20 晶體管NPN	RS232 + RS485	無
C48S0P-e	C48S2P-e	C48S0P	C48S2P	28	20 晶體管PNP	RS232 + RS485	無
C60S0R-e	C60S2R-e	C60S0R	C60S2R	36	24 繼電器	RS232 + RS485	無
C60S0T-e	C60S2T-e	C60S0T	C60S2T	36	24 晶體管NPN	RS232 + RS485	無
C60S0P-e	C60S2P-e	C60S0P	C60S2P	36	24 晶體管PNP	RS232 + RS485	無

T系列經典PLC主機 ?海為T(mén)系列PLC主機使用說明

帶以太網型號

型號

產品規格

外形尺寸
WxHxD

24V DC

220V AC

24V DC

220 VAC

高速脈沖
輸入

高速脈沖
輸出

通訊口

最大擴
展模塊

T16S0R-e

T16S2R-e

T16S0R

T16S2R

8 繼電器

2 路A/B相
(4點)200KHz

RS232+RS485,
最多5個

Haiwell 海為PLC

93×95×82mm

T16S0T-e

T16S2T-e

T16S0T

T16S2T

8 晶體管NPN

2 路A/B相
(4點)200KHz

RS232+RS485,
最多5個

T16S0P-e

T16S2P-e

T16S0P

T16S2P

8 晶體管PNP

2 路A/B相
(4點)200KHz

RS232+RS485,
最多5個

T16M0R-e

T16M2R-e

T16M0R

T16M2R

6繼電器

RS232+RS485,
最多5個

T16M0T-e

T16M2T-e

T16M0T

T16M2T

6 晶體管NPN

RS232+RS485,
最多5個

T20M0R-e

T20M2R-e

T20M0R

T20M2R

6繼電器

RS232+RS485,
最多5個

Haiwell 海為PLC

131×95×82mm

T20M0T-e

T20M2T-e

T20M0T

T20M2T

6 晶體管NPN

RS232+RS485,
最多5個

T24S0R-e

T24S2R-e

T24S0R

T24S2R

8 繼電器

2 路A/B相
(4點)200KHz

RS232+RS485,
最多5個

T24S0T-e

T24S2T-e

T24S0T

T24S2T

8 晶體管NPN

2 路A/B相
(4點)200KHz

RS232+RS485,
最多5個

T24S0P-e

T24S2P-e

T24S0P

T24S2P

8 晶體管PNP

2 路A/B相
(4點)200KHz

RS232+RS485,
最多5個

T32S0R-e

T32S2R-e

T32S0R

T32S2R

16 繼電器

2 路A/B相
(4點)200KHz

RS232+RS485,
最多5個

T32S0T-e

T32S2T-e

T32S0T

T32S2T

16 晶體管NPN

2 路A/B相
(4點)200KHz

RS232+RS485,
最多5個

T32S0P-e

T32S2P-e

T32S0P

T32S2P

16 晶體管PNP

2 路A/B相
(4點)200KHz

RS232+RS485,
最多5個

T48S0R-e

T48S2R-e

T48S0R

T48S2R

20 繼電器

2 路A/B相
(4點)200KHz

RS232+RS485,
最多5個

Haiwell 海為PLC

177×95×82mm

T48S0T-e

T48S2T-e

T48S0T

T48S2T

20晶體管NPN

2 路A/B相
(4點)200KHz

RS232+RS485,
最多5個

T48S0P-e

T48S2P-e

T48S0P

T48S2P

20 晶體管PNP

2 路A/B相
(4點)200KHz

RS232+RS485,
最多5個

T60S0R-e

T60S2R-e

T60S0R

T60S2R

24 繼電器

2 路A/B相
(4點)200KHz

RS232+RS485,
最多5個

T60S0T-e

T60S2T-e

T60S0T

T60S2T

24 晶體管NPN

2 路A/B相
(4點)200KHz

RS232+RS485,
最多5個

T60S0P-e

T60S2P-e

T60S0P

T60S2P

24 晶體管PNP

2 路A/B相
(4點)200KHz

RS232+RS485,
最多5個

H系列經典PLC主機 ?海為H系列PLC主機使用說明

帶以太網型號		型號		產品規格						外形尺寸 WxHxD
24V DC	220V AC	24V DC	220V AC	DI	DO	高速脈沖輸入	高速脈沖輸出	通訊口	最大擴 展模塊	外形尺寸 WxHxD
H16S0R-e	H16S2R-e	H16S0R	H16S2R	8	8 繼電器	4 路A/B相 (8點)200KHz		RS232+RS485, 最多5個	7	93×95×82mm
H16S0T-e	H16S2T-e	H16S0T	H16S2T	8	8 晶體管NPN	4 路A/B相 (8點)200KHz	4 路A/B相 (8點)200KHz	RS232+RS485, 最多5個	7
H16S0P-e	H16S2P-e	H16S0P	H16S2P	8	8 晶體管PNP	4 路A/B相 (8點)200KHz	4 路A/B相 (8點)200KHz	RS232+RS485, 最多5個	7
H24S0R-e	H24S2R-e	H24S0R	H24S2R	12	12 繼電器	4 路A/B相 (8點)200KHz		RS232+RS485, 最多5個	7
H24S0T-e	H24S2T-e	H24S0T	H24S2T	12	12 晶體管NPN	6 路A/B相 (12點)200KHz	6 路A/B相 (12點)200KHz	RS232+RS485, 最多5個	7
H24S0P-e	H24S2P-e	H24S0P	H24S2P	12	12 晶體管PNP	6 路A/B相 (12點)200KHz	6 路A/B相 (12點)200KHz	RS232+RS485, 最多5個	7
H32S0R-e	H32S2R-e	H32S0R	H32S2R	16	16 繼電器	4 路A/B相 (8點)200KHz		RS232 + RS485, 最多5個	7	131×95×82mm
H32S0T-e	H32S2T-e	H32S0T	H32S2T	16	16 晶體管NPN	6 路A/B相 (12點)200KHz	6 路A/B相 (12點)200KHz	RS232+RS485, 最多5個	7
H32S0P-e	H32S2P-e	H32S0P	H32S2P	16	16 晶體管PNP	6 路A/B相 (12點)200KHz	6 路A/B相 (12點)200KHz	RS232+RS485, 最多5個	7
H40S0R-e	H40S2R-e	H40S0R	H40S2R	20	20 繼電器	4 路A/B相 (8點)200KHz		RS232+RS485, 最多5個	7
H40S0T-e	H40S2T-e	H40S0T	H40S2T	20	20 晶體管NPN	8 路A/B相 (16點)200KHz	8 路A/B相 (16點)200KHz	RS232+RS485, 最多5個	7
H40S0P-e	H40S2P-e	H40S0P	H40S2P	20	20 晶體管PNP	8 路A/B相 (16點)200KHz	8 路A/B相 (16點)200KHz	RS232+RS485, 最多5個	7
H60S0R-e	H60S2R-e	H60S0R	H60S2R	36	24 繼電器	4 路A/B相 (8點)200KHz		RS232+RS485, 最多5個	7	177×95×82mm
H60S0T-e	H60S2T-e	H60S0T	H60S2T	36	24 晶體管NPN	8 路A/B相 (16點)200KHz	8 路A/B相 (16點)200KHz	RS232+RS485, 最多5個	7
H60S0P-e	H60S2P-e	H60S0P	H60S2P	36	24 晶體管PNP	8 路A/B相 (16點)200KHz	8 路A/B相 (16點)200KHz	RS232+RS485, 最多5個	7
